PMW 110

The model 110 is the perfect Power Spray Washer for the small shop

as well as an inexpensive additional washer for the large shops.

With a 12 ga. steel cabinet, a 2 hp. main pump, this rugged

machine is designed for small parts to V-8 blocks. The model 110

is safe, portable and efficient method for commercial and industrial applications.

PMW 112

The model 112 is designed for small shops and its 3 HP pump

gets jobs done quick. The standard, heavy duty construction of

this washer will ensure years of service while improving the standard

of cleanliness in your shop. The model 112 utilizes hot water soluble cleaning

agents. Standard 26″ dia. turntable with 32″ of working height.

PMW 113

The Model 113 is the perfect washer for small shops. This

washer has the same features and working size as the Model 112

but is fully insulated for efficiency and has a larger fluid capacity

making this unit ideal for constant use. It can accommodate up to

500 lbs and withstand multi-loading blocks, heads, transmissions or parts.

PMW 412

With a standard 5 hp. Pump, 26″ dia. turntable, and a 40″ working

height this washer, the model 412 is ideal for commercial rebuilders

and larger shops.  It boasts a 5 H.P. pump, 12 Kw. electric heat,

insulated cabinet, 70 gal. reservoir, electric lockout and a 5 cu. ft.

parts basket standard. Turntable easily handles loads up to 800 lbs.

PMW 612

Perfect for larger shops because the 36″ dia. turntable and 42″

of working height it will handle just about any cleaning job with

ease (up to 1000 lbs. of parts.) The model 612 has a 7.5 hp. pump

that sprays 110 gpm at 60 psi, 12 Kw. electric heat, insulated cabinet,

electric lockout, 120 gal, reservoir and 5 cu. ft. parts basket standard.

PMW 812

The 812 series machines are available in 6 standard sizes up to a 6 ft.

dia. turntable with 60″ working height and 2000 lb capacity. The door

mounted turntable design is built to provide complete accessibility.

The labyrinth door design eliminates the need for expensive replacement s

eals. Your customization will be perfect for its application.



Click Here to View All Cuda Parts Washer Models

CUDA 2530

The Cuda 2530 is the smallest in the front-load automatic parts washer models.

The 2530 features a turntable diameter of 25-inches, working height of 30-inches,

and load capacity of 500 lbs. The 2530 Series is equipped with a 3 HP vertical

seal-less pump producing 50 GPM at 45 PSI.

CUDA 2840

The Cuda 2840 is the next larger size in the front-load automatic parts washer

models. The 2840 features a turntable diameter of 28-inches, working height of

40-inches, and load capacity of 750 lbs. The 2840 Series is equipped with a

3 HP vertical seal-less pump producing 50 GPM at 45 PSI.

CUDA 2848

The Cuda 2848 features a turntable diameter of 28-inches, working height of

48-inches, and load capacity of 750 lbs. The 2848 Series is equipped with a

5 HP vertical seal-less pump producing 110 GPM at 50 PSI.

CUDA 4860

The Cuda 4860 features a turntable diameter of 48-inches, working height of

60-inches, and load capacity of 5000 lbs. The 4860 Series is equipped with a

7.5 HP vertical seal-less pump producing 200 GPM at 50 PSI, and has a

156-gallon sump capacity.

CUDA SJ-15

The newest addition to the Cuda top load line-up, the SJ-15 uses

a patented spray wash technology which eliminates the need for a

drive motor, gears and pulleys. Using a water-propelled spray arm with

23 nozzles that spin around a stationary parts basket, parts are hit from

every angle while being cleaned.

CUDA 2216

At only 32 inches wide, the Cuda 2216 Series parts washer is our most

compact top-loading parts washer. The Cuda 2216 Series has a 500-lb. load

capacity, and a 22-inch turntable diameter. The Cuda 2216 Series has a

1 HP pump motor producing 28 GPM @ 30 PSI.

CUDA 2412

At only 35 inches wide, the Cuda 2412 Series parts washer has a 250-lb.

load capacity, and a 24 inch turntable diameter. The Cuda 2412 Series has a 1

/2 HP flush sealed pump and an upper drive arm that rotates the turntable.

It’s versatile for use anywhere in the shop.

CUDA 2518

The 2518 is the top of the line in the Cuda top-load parts washers.

Built to withstand the harsh demands of everyday use, it comes standard with

a time-tested chain drive assembly and a virtually maintenance-free sealess

pump. Extra-easy access to the sump and removable debris screen set it apart

from other top-loaders on the market. The Cuda 2518 Series has a 500-lb. load

capacity, a 25-inch turntable diameter and 18-inch working height.

Click Here to View all Viking Part Washer Models

HP 2233 Washer

Sloped reservoir aids in draining and is easy to clean

10HP, 3-Phase seal-less pump

Positive turntable drive system

High impact spray nozzles for better cleaning

Roll-out turntable design

Labyrinth style door – no seals

Insulated cabinets are energy efficient and provides quiet operation

SC 2245 Washer

0-30 minute cleaning cycle timer

SC 2233 is narrow enough to pass through a 30” wide door

Large-capacity filter traps debris and is easily removed for cleaning

Door activated safety switch

Turntable on-off switch for concentrated cleaning

Insulated cabinets

Vertical, seal-less pump

7-day timer

SC 2233 Washer

0-30 minute cleaning cycle timer

SC 2233 is narrow enough to pass through a 30” wide door

Large-capacity filter traps debris and is easily removed for cleaning

Door activated safety switch

Turntable on-off switch for concentrated cleaning

Insulated cabinets

Vertical, seal-less pump

7-day timer

SKS Series Wash Systems

Sloped bottom makes reservoir cleaning easy

Seal-less, high pressure pump

Heavy-duty door latch assures sealing

Manual rinse system (Not available on the SKS 2233)

Electric or gas heated machines are available in standard 3Ø, 230V or optional 1Ø power

Large capacity fi lter traps debris to protect nozzles and is easily removed for cleaning

Oil skimmer is standard equipment (optional on SKS 2233)

Heavy gauge construction throughout the machine

Insulated cabinet, including the top, saves energy and reduces noise

HP 2833 Spray Washer

10HP, 3-Phase seal-less pump

Positive turntable drive system

High impact spray nozzles for better cleaning

Sloped reservoir aids in draining and is easy to clean

Insulated cabinets are energy efficient and provides quiet operation

Roll-out turntable design

Labyrinth style door – no seals

RW 4060 Cabinet Washer

Heavy-duty, 40” turntable locks to prevent movement while loading parts

High impact nozzles provide more effective cleaning

10 Ga. cabinet construction

Positive-drive turntable

Labyrinth-style door seal

Vertical shaft, 20 HP pump

Features & Specifications

Actual distillation, not just simple filtration Small, light-weight and portable – 29 lbs

Can be incorporated into any parts washing or bulk system Easy to use, sets up in

minutes StillClean can be customized to your process to maximize savings and

productivity Recycles a wide range of 105 to 150 degree flash point  solvents Outputof 1

gallon per hour of pure clean solvent 115 VAC I 5.4 Amps power requirements 0.5 CFM ®

80 PSI compressed air requirements ETL listed to UL Standards 201 and 2208

Click Here to View all Pro Ultrasonic Models

PRO 1911

Dimensions: 40” long (with lid open) x 18” wide x 16” high

Cleaning tank: 19” long x 11” wide x 10” deep

Total liquid capacity: 9 gallons

Ultrasonic Power: 1200 watts peak / 600 watts avg

Heat Power: 1000 watts

Electrical Requirements: 110V, 14A

PRO 2013

Dimensions: 48” long (with lid open) x 25” wide x 36” high

Cleaning tank: 20” long x 13” wide x 14” deep

Total liquid capacity: 16 gallons

Ultrasonic Power: 2400 watts peak / 1200 watts avg.

Heat Power: 800 watts

Electrical Requirements: 110V, 15A

PRO 3216

Dimensions: 70” long (with lids open) x 27” wide x 36” high

Cleaning tank: 32” long x 16” wide x 14” deep

Total liquid capacity: 31 gallons

Ultrasonic Power: 3600 watts peak / 1800 watts avg.

Heat Power: 3000 watts

Electrical Requirements:220V, 1Ø or 208V, 3Ø

PRO 1208

Dimensions: 30” long (with lid open) x 13” wide x 18” high

Cleaning tank: 12” long x 8” wide x 9” deep

Total liquid capacity: 3 gallons

Ultrasonic Power: 600 watts peak / 300 watts avg

Heat Power: 500 watts

Electrical Requirements: 110V, 7A

PRO 4230

Dimensions: 56” long (add 24” with drain shelf) x 40” wide x 36” high

Cleaning tank: 42” long x 30” wide x 18” deep

Overflow tank: 42” long x 6” wide x 18” deep

Total liquid capacity: 105 gallons

Ultrasonic Power: 10,800 watts peak / 5400 watts avg.

Heat Power: 4000 watts

Electrical Requirements: 208V, 3Ø

PRO 3624

Dimensions: 50” long (add 18” with drain shelf) x 40” wide x 36” high

Cleaning tank: 36” long x 24” wide x 14” deep

Overflow tank: 36” long x 6” wide x 14” deep

Total liquid capacity: 65 gallons

Ultrasonic Power: 7200 watts peak / 3600 watts avg.

Heat Power: 4000 watts

Electrical Requirements: 220V, 1Ø or 208V, 3Ø

PRO 2013D2

Dimensions: 70” long (with lids open) x 27” wide x 36” high

Cleaning tank: 32” long x 16” wide x 14” deep

Total liquid capacity: 31 gallons

Ultrasonic Power: 3600 watts peak / 1800 watts avg.

Heat Power: 3000 watts

Electrical Requirements:220V, 1Ø or 208V, 3Ø

In practically every industry we operate in, corrosion and rust are problems we’ve

encountered. From powertrain components to plating in printed circuit board, expensive

materials are subject to the rigors of damp environments and prolonged periods of time in

shipment or storage.

That is why we offer Rust Protection solutions for your components, tools and equipment

from the negative effects of rust and long-term corrosion. We offer PREVENTIVE

SOLUTIONS (like our Zerust VCI bags and Rust Inhibiting TRANSBRITE RustFREE

detergent) as well as REMOVAL PRODUCTS  like our Zerust Axxaclean series.

Rust Removers

In the event of rust, you have the option of using one of our rust and tarnish removers for

the rework and recovery of metal items!

We offer a range of technologies to meet any application. We offer pH neutral products you

can dip parts in and more aggressive, acidic products that also inhibit flash corrosion on

cleaned surfaces.

Rust Protection

In order to stop rust and corrosion from happening in the first place, use one of our

preventative options that will inhibit corrosion from the start. For aqueous cleaning, our

TRANSBRITE RustFREE will augment your detergent for advanced corrosion inhibition.

We offer packaging solutions such as VCI bags and Kraft Paper utilizing advanced

corrosion-inhibiting formulations for short or long-term shipment and storage. Our liquid-

based coatings will provide excellent protection even in the harshest environments.

TRANSBRITE TurboCHARGE Additive is a Premium Quality Liquid Booster that is engineered to

be used with all TRANSBRITE Detergents when additional carbon removal is necessary.

TRANSBRITE TurboCHARGE is specifically designed to quickly and effectively attack and remove

carbon byproducts produced by the combustion process, such as burnt on carbon, oil, grease, and

all other contaminants. TRANSBRITE TurboCHARGE can be directly added into the wash sump or

immersion tank of all aqueous industrial parts washers.

Available Sizes: 1 gallon bottles, 4×1 gallon cases, 5 gallon pails, and 55 gallon drums

TRANSBRITE DirtBUSTER is a Heavy Duty, Multi-Purpose Liquid Detergent capable of cleaning

the toughest soils and contaminants associated with today’s remanufacturer & rebuilder.

TRANSBRITE DirtBUSTER is capable of cleaning and degreasing everything from hard-surface

concrete shop floors & walls, to equipment, and company vehicles. As a concrete shop floor

cleaner, TRANSBRITE DirtBUSTER will increase employee safety & production while decreasing

slip-and-fall accidents. TRANSBRITE DirtBUSTER ELEVATES YOUR FLOOR CARE TO FLOOR

SAFETY!

Available Sizes: Super Concentrated Kits (makes 30 gallons of concentrate) and 55 gallon drums

TRANSBRITE FloorCLEAN is a Heavy Duty Powdered Detergent capable of cleaning and

degreasing the toughest soils and contaminants found on today’s manufacturers’,

remanufacturers’ & rebuilders’ production shop floors. TRANSBRITE FloorCLEAN is a superior

fast-acting shop floor cleaner that will increase employee safety & production while decreasing

slip-and-fall accidents. TRANSBRITE FloorCLEAN ELEVATES YOUR FLOOR CARE TO FLOOR

SAFETY!

Available Sizes: 50 pound pails, 100 pound drums, and 400 pound drums

TRANSBRITE SuperBREAK RTU is a Multi-Purpose Liquid Spray Cleaner/Degreaser formulated

for the cleaning of all parts & surfaces not harmed by water. TRANSBRITE SuperBREAK RTU is

capable of cleaning everything, from floors to ceilings found in the working environment.

TRANSBRITE SuperBREAKRTU’s enhanced grease cutting formula is often effective without

scrubbing, just spray and wipe clean. TRANSBRITE SuperBREAK RTU removes greases, oils,

inks, some paints and heavy soils.

Available Sizes: 12×32 fl oz. 4×1 gallon cases, 5 gallon bag-n-box, and 55 gallon drums
